1.1

Manufacturer

MICROLIFT

1.2

Model

ET20

1.4

Operate Type

Walkie

1.5

Load Capacity

Q(kg)

2000

1.6

Load Center

c(mm)

600

1.9

Wheelbase

y(mm)

1418

Weight

2.1

Service Weight(Incl. Battery)

kg

612

Wheels,Chassis

3.1

Tyre Type

PU

3.2

Tyre Size,Drive Wheels

mm

Φ230x70

3.3

Tyre Size,Load Wheels

mm

Φ80x80

3.4

Tyre Size,Balance Wheels

mm

Φ115x55

3.5

Wheels,Numbers(x= drive wheel)

1+2/4

Dimensions

4.2

Height,Mast lowered

h1(mm)

－

4.3

Free Lift

h2(mm)

－

4.4

Lift Height

h3(mm)

200

4.5

Height,Mast Extended

h4(mm)

－

4.9

Height of tiller arm,Min/Max

h14(mm)

1010/1480

4.15

Fork Height, Lowered

h13(mm)

85

4.19

Overall Length

l1(mm)

1750

4.21

Overall Width

b1/b2(mm)

710

4.22

Fork Dimension

l/e/s(mm)

1150x160x50

4.25

Outside Fork Width

b5(mm)

540/685

4.32

Ground Clearance

m2(mm)

35

4.33

AST,1000X1200 pallet crossways

ast1(mm)

1940

4.34

AST,800X1200 pallet crossways

ast2(mm)

1900

4.35

Outer Turning Radius

wa(mm)

1575

Performance

5.1

Travel Speed, Laden/Unladen

km/h

5.0/5.5

5.2

Lifting Speed, Laden/Unladen

m/s

0.05/0.06

5.3

Lowering Speed, Laden/Unladen

m/s

0.05/0.06

5.8

Max Gradeability, Laden/Unladen

%

5.0/10.0

Drive

6.1

Drive Motor Rating S2 60Min

kw

1.50AC

6.2

Lifting Motor Rating S3 15%

kw

2.20DC

6.4

Battery Voltage/Capacity(5h)

V/Ah

24/210(Industry)

Others

7.1

Controller

PG/CURTIS

7.2

Service Brake

Regenerating

7.3

Parking Brake

Electromegnetic
